用途：適用于各種局部凈化設備和潔凈廠房，在常溫，常壓條件下環境空氣的凈化
特點
構成材料及運行條件Materials and operating conditions
| 框材 External frame | 鋁型材或木框 Aluminum or wood |
| 密封物 Sealant | 聚胺脂膠 Gel-glue |
| 分隔物 Separator | 膠板紙或鋁膜 Sized paper or aluminum |
| 密封條 Gasket | 醋酸乙酯 EVA |
| 濾料 Filter media | 玻纖濾紙 Glass fiber |
| 使用最高溫度 Maximum operating temperature | 80℃ |
| 使用最高濕度 Maximum operating humidity | 80% |
構成材料及運行條件Materials and operating conditions
| 型號 model | 外形尺寸 Outside dimensions (mm) | 額定風量 Rated air flow (m3/h) | 初阻力 Initial resistance (Pa) | 效率(比色法) Efficiency (%) | 容塵量 Dust capacity (g) | 重量 Weight (Kg) |
| GK-4MA-C | 305×305×220 | 400 | ≤220 | ≥99.99 | 300 | ≈3 |
| GK-4MB-C | 320×320×220 | 400 | ≤220 | ≥99.99 | 350 | ≈3.4 |
| GK-5MA-C | 350×350×220 | 500 | ≤220 | ≥99.99 | 400 | ≈4 |
| GK-5SB-C | 305×610×150 | 500 | ≤220 | ≥99.99 | 400 | ≈3.2 |
| GK-10SA-C | 600×600×150 | 1000 | ≤220 | ≥99.99 | 600 | ≈6.2 |
| GK-10MC-C | 484×484×220 | 1000 | ≤220 | ≥99.99 | 600 | ≈6.5 |
| GK-10SB-C | 610×610×150 | 1000 | ≤220 | ≥99.99 | 600 | ≈7.7 |
| GK-13SA-C | 820×600×150 | 1300 | ≤220 | ≥99.99 | 750 | ≈8.5 |
| GK-13SB-C | 720×760×150 | 1300 | ≤220 | ≥99.99 | 800 | ≈9.5 |
| GK-15MA-C | 726×484×220 | 1500 | ≤220 | ≥99.99 | 750 | ≈11.5 |
| GK-15SB-C | 915×610×150 | 1500 | ≤220 | ≥99.99 | 800 | ≈10 |
| GK-15MC-C | 630×630×220 | 1500 | ≤220 | ≥99.99 | 900 | ≈13 |
| GK-20MA-C | 968×484×220 | 2000 | ≤220 | ≥99.99 | 1200 | ≈15 |
| GK-20SB-C | 1220×610×150 | 2000 | ≤220 | ≥99.99 | 1200 | ≈12.5 |
| GK-23MA-C | 945×630×220 | 2300 | ≤220 | ≥99.99 | 1400 | ≈19 |
| GK-30MA-C | 1260×630×220 | 3000 | ≤220 | ≥99.99 | 1800 | ≈23 |
