構成材料及運行條件Materials and operating conditions
| 框材 External frame | 鋁型材Aluminum |
| 密封物 Sealant | 聚胺脂膠 Gel-glue |
| 分隔物 Separator | 熱熔膠 Hot-melt |
| 濾料 Filter media | 玻纖濾紙 Glass fiber |
| 使用最高溫度 Maximum operating temperature | 80℃ |
| 使用最高濕度 Maximum operating humidity | 80% |
| 密封條 Gasket | 醋酸乙酯 EVA |
型號尺寸及其他參數 standard specification
| 型號 model | 外形尺寸 Outside dimensions (mm) | 額定風量 Rated air flow (m3/h) | 容塵量 Dust Capacity (g) | 初阻力 Initial resistance (Pa) | 效率(比色法) Efficiency (%) | 重量 Weight (Kg) |
| GKYS-1.1SSA-E | 305×305×35 | 110 | 100 | ≤220 | ≥99.99 | ≈0.6 |
| GKYS-4.5SSA-E | 610×610×35 | 450 | 300 | ≤220 | ≥99.99 | ≈2.3 |
| GKYS-6.8SSA-E | 915×610×35 | 680 | 450 | ≤220 | ≥99.99 | ≈3.5 |
| GKYS-1.8SA-E | 305×305×50 | 180 | 130 | ≤220 | ≥99.99 | ≈0.8 |
| GKYS-7SA-E | 610×610×50 | 700 | 450 | ≤220 | ≥99.99 | ≈3 |
| GKYS-11SA-E | 915×610×50 | 1100 | 650 | ≤220 | ≥99.99 | ≈4.5 |
| GKYS-2.5MA-E | 305×305×69 | 250 | 150 | ≤220 | ≥99.99 | ≈1 |
| GKYS-10MA-E | 610×610×69 | 1000 | 580 | ≤220 | ≥99.99 | ≈4 |
| GKYS-15MA-E | 915×610×69 | 1500 | 800 | ≤220 | ≥99.99 | ≈6 |
| GKYS-3LA-E | 305×305×80 | 300 | 180 | ≤220 | ≥99.99 | ≈1.2 |
| GKYS-13LA-E | 610×610×80 | 1300 | 650 | ≤220 | ≥99.99 | ≈4.5 |
| GKYS-19LA-E | 915×610×80 | 1900 | 1000 | ≤220 | ≥99.99 | ≈6.8 |
| GKYS-19LLA-E | 915×610×90 | 1900 | 1000 | ≤220 | ≥99.99 | ≈7.5 |
